This newly updated version of the IrayUSA RH25 takes the extremely popular original version and adds numerous improvements, making it the pinnacle of micro thermal monoculars that can do it all.
Please note that images show the RH25v2 with certain accessory mounts which are not directly included and must be purchased separately. We recommend purchasing the RH25v2 with the Iray MQD and Iray Pictail accessories for best clip on mounting experience when pairing with 1.54" height optics. Or, for 1.93" height day optics, pair with the Iray Flip to Side Mount.
Manufacturer's Description
The RICO MICRO has been regarded as one of the most powerful and versatile thermal optics on the market. The new RH25 V2 is an evolution that keeps the well-known compact form factor and advanced feature set, while adding user-requested features and system enhancements focused on improving image quality and ease-of-use.
In its newest variation, the RH25 V2 has been updated to provide users with powerful enhancements while retaining the versatility that our customers love; use it as a handheld scanner, helmet-mounted monocular, weapon sight, or thermal clip-on. New models feature a machined magnesium alloy housing to reduce weight. An added USB-C port now allows for simplified file transfer and the ability to power the MICRO from an external battery pack. The internal video recorder now includes crisp audio and 64 GB of internal storage. An improved 1440×1080 AMOLED display and is paired with a new eyepiece that offers more comfortable viewing and clip-on compatibility for optics up to up to 6× magnification. The new display provides a physical viewing area that is 80% larger than the previous generation, with 97% more total pixels. The MICRO V2 also uses InfiRay’s latest 12 µm sensor, an improved NETD rating of ≤18mK, and a manual-focus f/1.0 objective lens to create an image that is unlike anything in its class.
-
Optics
Display TypeAMOLED
Eye Relief45mm
Objective Focal Length25mm
Digital Magnification4X
Diopter Range-5 to +2
Vertical Angular Field of View13.1
Horizontal Angular Field of View17.5
Focusing MechanismManual Focus
Objective F#1.0
Objective Diameter25mm
Objective Lens MaterialGermanium
Display Resolution1440×1080
Detection Range1375 Yards
Optical Magnification1X
-
Features & Performance
Warranty5 Years
Startup Time<10 Seconds, Instant from Standby
Color PalettesWhite Hot, Black Hot, Red Hot, Color
Picture-in-PictureNo
Storage Capacity64GB
Connector OutputPower/Data
User-Updatable FirmwareYes
Mobile AppYes
Run Time6.5+
Power SourceUSB-C External, 18650 Battery
Stand-by ModeYes
Reticle7
Connector TypeUSB-C
External Power SourceUSB-C
Country of ManufactureChina
WifiYes
Onboard RecordingYes
Image CaptureYes
-
Sensor Specifications
Sensor TypeInfiRay MICRO II
Sensor Pixel Size12μm
Thermal Sensitivity<15mk
Non-Uniformity Correction (NUC)Manual, Automatic, Semi-Automatic
Sensor Frame Rate60hz
Device TechnologyThermal Imaging
Sensor Resolution640×480
-
-
